4. TSM Service Program 1/2010 4 - 147
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
3. Press the BICP Pump or KP Pump
key again to start a pump
calibration.
The piston pump runs two minutes and stops.
4. Press the
key, which appears automatically after 2 minutes.
5. Enter the suction delivery volume (200 ml - residual volume = delivery
volume) as reference value.
6. Press
key to confirm.
7. Confirm and store completed calibration procedure with
key.
Note: Generally, follow the instruction for UFP calibration if using a
balance.
4.8.3.11.2 Calibration UF Pump with Balance
The accuracy of the UFP calibration is essential for the precise weight
reduction of a patient during dialysis.
• Balance
• Tubing clamp
1. Clamp and remove inlet tubing from UFP. Connect another tubing to the
UFP and immerge tubing into a container with approx. 200 ml
demineralised water.
2. Press the UF Pump
key to prime the tubings.
Wait a few seconds to fully prime the tubings.
3. Press again the UF Pump
key to stop the UFP.
The UFP will rotate back into its initial position.
4. Press
key.
5. Remove the filled tubing carefully from the measuring cylinder, measure
the weight and note value.
6. Replace the tubing carefully in the measuring cylinder.
7. Press the UF Pump
key to start the calibration procedure.
The UFP runs approx. two minutes and stops. It will rotate back into its
initial position.
8. After the UF pump has stopped, remove the tubing carefully from the
measuring cylinder, measure the weight and note value.
9. Press
key.
10. Enter the calculated delivery volume as reference value.
First measurement – second measurement = delivery volume
11. Press
key to confirm.
12. Confirm and store completed calibration procedure with
key.
Note: The calibration data is saved only after the bit sequence 0-1-0 (for
detailed information see 4.8.3.1 General Calibration Information).
