B. Braun Dialog+ - Solenoid Valves and Throttle

7. Spare Parts List 1/2010 7 - 57
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
DBK
VVB
VEB
VZ
PE
VBKS
VBICP
VBKO
2,3,4,5
3,6
1
5
2
3
4
7.17.2 Solenoid Valves and Throttle
1
34560289 1 Solenoid valve 2/2 way
connector/connector (DPP)
2
34770925 5 Plug
3
34770852 5 O-ring 11.1 x 1.6
4
34771050 10 Pressure spring 500 mmHg
5
34771352 3 Centre disc
6
3451916A 5
Tubing connector
∅
8 x 1/8"
plastic
