3.4.5.7 PC Health Status
Dialog+ SW 9.xx
CFC/CR
Compact Flash Card/Card-Reader
(Default Setting)
CPU Temp 50
o
C
Vcore 1.26V
Vmem 2.60V
+3.3 V 3.39V
+5 V 5.13V
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save Exit Setup
Exit Without Saving
3.4.5.8 Change Parameters in CMOS Setup
The LX800 motherboard is delivered ex works with
a special default setting for a Dialog+ machine
with a CFC.
If necessary, the BIOS setup must be adapted to
the specific hardware present in a Dialog+ or
Dialog Advanced machine. The example shows a
general approach to change a parameter in the
BIOS according to the BIOS setup table for the
LX800 motherboard.
Example:
Change parameter in
Standard CMOS Features
for Dialog+ with HDD (CFC)
The example shows how the
IDE Primary Master
parameter is changed from
None
to
Auto
for a
Dialog+ with a hard disk drive (CFC) (see
paragraph 3.4.5.1 Standard CMOS Features).
1.
Connect PC keyboard (with PS2 connector) to
LX800 motherboard.
2.
Switch on Dialog+ and press the
Delete/Del
key to enter the BIOS (when keyboard status
LEDs shortly light up).
3.
Press
Enter
key to go to the
Standard CMOS
Features
menu.
4.
Move down to
IDE Primary Master
with the
Arrow
key.
Phoenix - AwardBIOS CMOS Setup Utility
Load Fail-Safe Defaults
!
Advanced BIOS Features Load Optimized Defaults
!
Advanced Chipset Features Set Supervisor Password
!
Integrated Peripherals Set User Password
!
Power Management Setup Save & Exit Setup
!
PnP/PCI Configuration Exit Without Saving
!
PC Health Staus
Esc : Quit
F10 : Save & Exit Setup
Time, Date, Hard Disk Type . . .
!
!!
! "
""
" #
##
# $
$$
$
: Select Item
!
Standard CMOS Features
Phoenix - AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy) Mon, Sep 29 2010 Item Help
Time (hh:mm:ss) 10 : 58 : 29
!
IDE Primary Master [ None ]
!
IDE Primary Slave [ None ]
Drive A [1.44M, 3.5 in.]
Drive B [ None ]
Video [EGA/VGA]
Halt On [All . But Disk/Key]
Base Menory 640K
Extended Memory 252672K
Total Memory 253440K
!
!!
!"
""
"#
##
#$
$$
$
:Move Enter:Select +/-/PU/PD:Value F10:Save Esc:Exit F1:General Hel
p
F5: Previous Values F6: Fail-Safe Defaults F7: Optimied Dafaults
None
Menu Level
Change the day, month,
year and century
