3.6.9.6 Read Patient Card
BlueCat
Removable Disk (X: - FSU USB Stick)
DISKTYPE
USER
05_Write_Calibration_Data
04_Write_Languages
06_Write_System_Configuration
09_Card_01_Read_Card_Image
09_Card_02_Write_Card_Image
09_Card_03_Read_Patient_Diskette
09_Card_04_Write_Patient_Diskette_to_Card
09_Card_05_Read_Patient_Card
This utility reads patient files from the patient card as
a compressed
patcard.zip
file to the FSU USB stick.
Read Patient Card
USB:\USER\09_Card_05_Read_Patient_Card\{Patient_
Name}\patcard.zip
Example:
USB:\USER\09_Card_05_Read_Patient_Card\Michael_
May\
patcard.zip
Patient_Name: Michael_May
Note:
If the patient name is not found on the card,
the
Unknown Patient
name is used.
Field Service Utilities V2.00 - Set000
CRC = XXXX - OK
01. Read Card Image (Card
→
USB Stick)
02. Write Card Image (USB Stick
→
Card)
03. Read Patient Diskette (Diskette
→
USB Stick)
04. Write Patient Diskette to Card (USB Stick
→
Card)
05. Read Patient Card (Card
→
USB Stick)
06. Write Patient Card (USB Stick
→
Card)
07. Remove All Patient Data
BP-
: move cursor up
BP+
: move cursor down
AQ
: back to previous menu
EQ
:
execute
1.
Press the
BP
hardware key, move cursor down
and select
09. Select Menu of Card Reader
Commands
in the main menu.
2.
Press the
BP
hardware key and move the cursor
down to select the utility.
3.
Press the
EQ
hardware key to execute the
utility.
•
Yes, patient card is read to USB stick
4.
Press the
AQ
hardware key to skip to the
previous menu.
•
No, patient card is not read to USB stick
Reading patient card.......
................
End of Read Patient Card . . .
Press the
‘AQ’
key to continue . . .
Remove all patient data from the FSU
USB stick after service with the utility
07.
Remove All Patient Data . This will delete
all patient data stored on the FSU USB
stick.
