B. Braun Dialog+ - Concentrate Suction Rods

7. Spare Parts List 1/2010 7 - 39
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
7.9.1 Concentrate Suction Rods
1
3451726A 1 Feed-through connector
2
34565213 10m
Silicone tubing 2.9 x 3 (10 m)
3
34517782 5 Disposable filter
4
34565248 10m
Silicone tubing 5 x 1.5 / blue (10 m)
5
34565230 10m
Silicone tubing 5 x 1.5 / red (10 m)
6
3451475A 1 Male connector (blue) with o-rings
7
3451476A 1 Male connector (red) with o-rings
8
34570004 5 O-ring 9.3 x 2.4
9
34565280 3m
Silicone tubing 3.2 x 1.6 (3 m)
10
3451728A 1 PE tube 4 x 1
with silicone tubing
2
3
1
4
5
7
6
10
9
8
