B. Braun Dialog+ - Basic Housing

7. Spare Parts List 1/2010 7 - 38
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
13
14
Basic Housing
7
3451489A 1 Swivel caster
8
3451490A 1 Swivel caster with brake
12
34518029 1 Strain relief
13
34560122 1 Double tubing connector 11xM12
stainless steel, for water inlet
14
34560130 1 Double tubing connector 11xM12
plastic, for dialysate outlet
-
34770852 5 O-ring 11.1 x 1.6
-
34771271 10 Tubing clamp 15/9
-
39234126 1 Tubing clamp 12-20 mm
-
34565140 50m PVC tubing 10 x 3, red
for water inlet
-
3456517A 1 PVC tubing 10 x 3 / red (3 m),
with two single ear clamps 19.5
for water inlet
-
34565159 50m PVC tubing 10 x 3, black
for dialysate outlet
-
3456518A 1 PVC tubing 10 x 3 / black (3 m),
with a single ear clamps 19.5 and a
tubing clamp 12-20 mm
for dialysate outlet
-
34565167 3m Silicone tubing 8 x 3.2 / red (3 m),
with two single ear clamps 17.5
external high temperature tubing
-
39224538 1 Single ear clamp 17.5
for external high temperature tubing
7
8
12
8
7
