7. Spare Parts List 1/2010 7 - 37
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
9
10
2
3
4
7,8
6
5
1
7.9 Basic Housing
1
3451962A 1 IV pole version 2
height adjustable
2
3451439A 1 Holder, top
3
34514929 1 Loudspeaker
4
3451438A 1 Holder, bottom
5
34517804 1 Front panel, bottom
6
34561269 1 Base platform
6
34519564 1 Silicone profile
7
3451489A 1 Swivel caster
8
3451490A 1 Swivel caster with brake
9
34560548 1 Card-Reader-Board
see 7.22 for details
10
3451487C 1 ABPM module M2009 with filter
see 7.19 for details
