3.4.5.4 Integrated Peripherals
Dialog+ SW 9.xx
CFC/CR
Compact Flash Card/Card-Reader
(Default Setting)
Master Drive PIO Mode [Auto]
Slave Drive PIO Mode [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
IDE DMA Transfer Access [Enabled]
IDE HDD Block Mode [Enabled]
Onboard FDC Controller [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
UART Mode Select [Normal]
x RxD, TxD Active Hi, Lo
x IR Transmission Delay Enabled
x UR2 Duplex Mode Half
x Use IR Pins IR-Rx2Tx2
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x EPP Mode Select EPP1.7
x ECP Mode Use DMA 3
Watch Dog Timer Select [Disabled]
Onboard Serial Port 3 [3E8]
Serial Port 3 Use IRQ [IRQ9]
Onboard Serial Port 4 [2E8]
Serial Port 4 Use IRQ [IRQ5]
3.4.5.5 Power Management Setup
x ACPI Function [Disabled]
Power Management [Disabled]
** PM Timers **
x Standby Mode Disabled
x Suspend Mode Disabled
HDD Power Down [Disabled]
MODEM Use IRQ [N/A]
PME Event Function [Disabled]
Soft-Off by PWR-BTTN [Instant-Off]
Power-On by Alarm [Disabled]
x Time (hh:mm:ss) Alarm 0
IRQ Wakrup Events [Press Enter]
IRQ1 (KeyBoard) [OFF]
IRQ3 (COM 2) [OFF]
IRQ4 (COM 1) [OFF]
IRQ5 (LPT 2) [OFF]
IRQ6 (Floppy Disk) [OFF]
IRQ7 (LPT 1) [OFF]
IRQ8 (RTC Alarm) [OFF]
IRQ9 (IRQ2 Redir) [OFF]
IRQ10 (Reserved) [OFF]
IRQ11 (Reserverd) [OFF]
IRQ12 (PS/2 Mouse) [OFF]
IRQ13 (Coprocessor) [OFF]
IRQ14 (Hard Disk) [OFF]
IRQ15 (Reserved) [OFF]
3.4.5.6 PnP/PCI Configuration
PNP OS Installed [No]
Init Display First [PCI Slot]
Reset Configuration Data [Disabled]
Resources Controlled By [Auto(ESCD)]
x IRQ Resources Press Enter
x Memory Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
