3.4.5.1 Standard CMOS Features
Dialog+ SW 9.xx
CFC/CR
Compact Flash Card/Card-Reader
(Default Setting)
Date (mm:dd:yy) Sun, mm:dd:yy
Time (hh:mm:ss) hh:mm:ss
IDE Primary Master [xxx xxx]
IDE HDD Auto-Detection [Press Enter]
IDE Primary Master [Auto]
Access Mode [Auto]
Capacity
-
Cylinder
-
Head
-
Precomp
-
Landing Zone
-
Sector
-
IDE Primary Slave [None]
Drive A [None]
Drive B [None]
Video [EGA/VGA]
Halt On [All, But Disk/Key]
Base Memory 640K
Extended Memory 252672K
Total Memory 253440K
3.4.5.2 Advanced BIOS Features
Virus Warning [Disabled]
CPU Internal Cache [Enabled]
First Boot Device
[USB-HDD]
Second Boot Device
[HDD-0]
Third Boot Device [Disabled]
Boot Other Drive [Disabled]
Swap Floppy Drive [Disabled]
Boot Up Floppy Seek [Disabled]
Boot Up NumLock Seek [On]
Gate A20 Option [Fast]
Typematic Rate Setting [Disabled]
x Typematic Rate (Chars/Sec) 6
x Typematic Delay (Msec) 250
Security Option [Setup]
OS Select For DRAM > 64MB [Non-OS2]
Full Screen LOGO Show [Enabled]
Small Logo(EPA) Show [Disabled]
Onboard Lan Boot ROM [Disabled]
3.4.5.3 Advanced Chipset Features
CPU Frequency [Auto]
x Memory Frequency [Auto]
CAS Latency [Auto]
Video Memory Size [8 M]
Output Display
[Panel & CRT]
Flat Panel Configuration [Panel Enter]
Resolution
[1024 x 768]
Refresh Rate [60 Hz]
HSYNC Polarity [Normal High]
VSYNC Polarity Active [Normal High]
SHFCLK Active Period [Free Running]
LP Active Period [Free Running]
Onboard Audio [Disabled]
Onboard USB1.1
[Enabled]
Onboard USB2,0
[Enabled]
Onboard DIE [Enabled]
Memory Hole At 15M-16M [Disabled]
