Dialog
+
SW 9.xx
The third page of the service overview can be selected with the Service Key
icon.
Click the Door icon to jump back to the initial menu.
Network Name
BSL-WAN:
Configuration
Serial No.: XXX
DBI SW: X.XX.X
System SW: X.XX
TLC SW: X.XX
Actual Language: XXX.XX.XX
BSL Serial No.: NONE
BSL FW: NONE
Option Selection
DBI: DBI-Nexadia
BSL: NONE
Baud Rate
Baud Rate (kBaud): XX.X
DBI Status
DBI active/
DBI not active
Network Status
BSL Connection/
BSL no Connection
Patient Card
ID: XXXX XXX XXX
Card Status: X
Nurse Selection
Enabled: YES/NO
Pin Code AT
Nurse Selection: YES/NO
Configuration: YES/NO
Time Setting
Server Date: NONE
Server Time: NONE
Dialog Date: NONE
Dialog Time: NONE
LLC ALARM:
0000 0000 0000 0000 0000 0000
MESSAGE:
0000 0000 0000 0000 0000 0000
LLS ALARM:
0000 0000 0000 0000 0000 0000
FREE M:
XXXX/XXX of XXXXX kB S: XX/XX MB
LLC/S & TLC Alarm Window LLC Message Window
Fig.: Third Page Service Overview in Therapy
