3. Repair Instructions 1/2010 3 - 65
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record (Dialog+ Hard Disk)
04. Write Languages (USB Stick
→
Dialog+ Hard Disk)
05. Write Calibration Data (USB Stick
→
Dialog+ Hard Disk)
06. Write System Configuration (USB Stick
→
Dialog+ Hard Disk)
07. Undo Last Written (USB Stick
→
Dialog+ Hard Disk)
08. USB Stick Self Test
09. Select Menu of Card Reader Commands
10. Read System Configuration (Dialog+ Hard Disk
→
USB Stick)
11. Read Calibration Data (Dialog+ Hard Disk
→
USB Stick)
12. Read All Trends (Dialog+ Hard Disk
→
USB Stick)
13. Read Screenshots (Dialog+ Hard Disk
→
USB Stick)
14. Get Error (ErrorDisk) (Dialog+ Hard Disk
→
USB Stick)
BP-
: move cursor up
BP+
: move cursor down
AQ
: exit – see
Important Note EQ
: execute
Important Note:
To prevent the corruption of USB stick, before removing it,
please press
AQ
then follow the instructions on the screen!
1.
Press
BP
and move the cursor down to select
the utility.
2.
Press
EQ
to execute the utility.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
Write Languages (USB Stick - > Dialog+ Hard Disk)
No source is found...
AQ
: back to main menu
An input screen can open with the following
information (see left figure), i.e. no languages were
found on the USB stick because the language
subdirectories are empty. Languages must be copied to
the USB stick before you can write languages to the
Dialog+ hard disk drive (CFC). Use the following
hardware key:
3.
Press
AQ
to go back to the main menu.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
Write Languages (USB Stick - > Dialog+ Hard Disk)
TREATMENT language: Italian – TREAT – 039-07-15
Pressing BPStart will select this language for TREATMENT
Are you sure to install this language to Dialog+?
BPStart
: select language for TREATMENT
AQ
: no
EQ
: yes
Languages must be downloaded to the USB stick before
they can be written to the Dialog+ hard disk drive
(CFC). An input screen opens to
Write Languages
(e.g.
Italian) to the hard disk drive (CFC) with the following
hardware keys:
BP
stopstop
:
if pressed before pressing the
EQ
HW key,
the selected
Treatment Language
is set after
copying as the active language
AQ
:
exit from the utility
EQ
:
starts the execution of the language copying
After successfully copying the language to the CFC the
version numbers of all languages available on the
Dialog+ are displayed. The language selected for
treatment is also marked.
4.
Press
EQ
to continue.
