B. Braun Dialog+ - Page 161

3. Repair Instructions 1/2010 3 - 99
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
Production Report
HD HDF Online US Default Modified
Options
ABPM inactive inactive active
DCI inactive inactive inactive
bioLogic RR

inactive inactive inactive
Kt/V inactive inactive inactive
Kt/V UV inactive inactive inactive
Card Reader inactive inactive active
HCT Crit-Line inactive inactive inactive
Low Level Options:
Double Pump
1) 1) 1)
Holder for BIC Cartridge
1) 1) 1)
DF Filter
1) 1) 1)
HDF Online
1) 1) 1)
Battery
1) 1) 1)
Nexadia-BSL (DBI)
1) 1) 1)
WAN-BSL (DBI)
1) 1) 1)
1) Setting depends on the configuration of the machine.
Blood Leak Detector Limit (2.7)
HD HDF Online US Default Modified
Standard Limit (0.5 ml/min at Haematocrite HK 0.45) active active inactive
AAMI Limit (0.35 ml/min at Haematocrite HK 0.25) inactive inactive active
Position Setting for BICP, KP and UFP (2.8.2)
Unit Default US Default Modified
BICP Parking - 180 180
KP Parking - 180 180
UFP Parking - 180 180
UFP Positive Pressure Test - 270 270
UFP Negative Pressure Test - 90 90
BICLF and ENDLF Ratio (2.10)
Unit Default US Default Modified
BICLF Ratio - 25 25
ENDLF Ratio - 31 36
BICLF Cart Ratio - 35 35
PV Alarm Window, PA Low Limit (2.12)
Unit Default US Default Modified
PV Alarm Window mmHg 100 100
PV Low Limit Position mmHg 35 35
PV Absolute Low Limit mmHg 20 20
PA Absolute Low Limit mmHg -200 -300
Pump Head Selection (2.13)
Unit Default US Default Modified
Pump Head 8 x 12 - active active
Pump Head 7 x 10 - inactive inactive
BPA and BPV (2.13.1)
Unit Default US Default Modified
BPA
µl/Head Revolution
12306 12306
BPV
µl/Head Revolution
12306 12306
HDF Online Substitution Pump OSP (2.15)
Unit Default US Default Modified
OSP
µl/Head Revolution
8300 8300
Level Regulation (2.16)
Unit Default US Default Modified
LRP (PPR) Slow % 60 60
LRP (PPR) Fast % 100 100
