B. Braun Dialog+ - Page 173

4. TSM Service Program 1/2010 4 - 4
BA-TE-DE08C M.KAY Dialog+ SW9xx_SM_Chapter 4-1-1_1-2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
4.8.3.10.4.2 Check 1 ‰ Blood Concentration 4-145
4.8.3.11 Calibration of Delivery Rate UFP, BICP and KP 4-146
4.8.3.11.1 Calibration BICP and KP Pump 4-146
4.8.3.11.2 Calibration UF Pump with Balance 4-147
4.8.3.11.3 Position Setting for BICP, KP and UFP 4-148
4.8.3.11.4 Stroke Value of BICP, KP and UFP 4-148
4.8.3.12 Calibration Safety Air Detector SAD 4-149
4.8.3.12.1 SAD Test after Calibration 4-150
4.8.3.13 Calibration BICLF and ENDLF Ratio 4-151
4.8.3.14 Calibration Load Cell 4-154
4.8.3.15 Calibration PV Alarm Window, PA Low Limit 4-155
4.8.3.16 Calibration Flow Rate of BPA and BPV/OSP 4-156
4.8.3.17 Infusion Density Substitution Pump 4-157
4.8.3.18 Stroke Value HDF Online Substitution Pump OSP 4-158
4.8.3.19 Level Regulation 4-159
4.8.3.20 Calibration Inlet Flow Pump Nonreturn Valve RVFPE 4-160
4.8.3.21 Calibration Dialysate Nonreturn Valve RVDA 4-162
4.8.3.22 Calibration Outlet Flow Pump Nonreturn Valve RVFPA 4-164
4.8.3.23 Calibration Dialyser Inlet Throttle Valve DDE 4-165
4.8.3.24 Calibration Pressure Reducer Valve DMV 4-167
4.8.3.25 Gap Arterial Tubing Clamp SAKA and Venous Tubing Clamp
Currentless Closed SAKV-SG
4-169
4.8.3.26 Arterial Tubing Clamp SAKA/Venous Tubing Clamp
Currentless Closed SAKV-SG
4-170
4.8.3.27 Setting Servomotor for Disinfection Valve VD 4-171
4.9 Production Report
4-173
4.9.1 Version Number Dialog
4-174
4.9.2 Low Level Options
4-175
4.10 Service Reports
4-176
