4. TSM Service Program 1/2010 4 - 24
BA-TE-DE08C M.KAY Dialog+ SW9xx_SM_Chapter 4-1-1_1-2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
BIC with NaCl
Machines with a BIC Cartridge Option
It is prohibited to use (select/activate) a bicarbonate concentrate with
NaCl if the machine has a BIC cartridge holder.
The unit mmol/l (NaCl concentration) must not be used if bicarbonate
concentrate with NaCl is applied.
You can select the current bicarbonate type with
NaCl:
• Bicarbonate with NaCl (4 - 7 mS/cm)
The BIC with NaCl is activated by pressing a free
section of the window.
The current acetate concentrate can be selected.
The name and the conversion factor [mS/cm per
mmol/l] can be entered if necessary for the
different acetate concentrates.
1. Click the BIC with NaCl window if necessary to
edit the bicarbonate name.
2. Click the Conversion window if necessary to
change the conversion factor [mS/cm per
mmol/l].
3. Click the Default Value window if necessary to
change the value [mS/cm].
4. Click the ACID icon if necessary to edit the
following parameters:
• Acid Concentrate Name
• Conversion Factor [mS/cm per mmol/l]
• Default Value
5. Scroll down to the end to set further
parameters.
Temperature Measurement Unit
You can set the temperature measurement unit between
o
C and F.
1. Click the F key to set to Fahrenheit.
Dialysate Flow
You can preset the dialysate flow for therapy.
1. Click the ml/min key to set the dialysate flow.
Dialysate Temperature
You can set the dialysate temperature for therapy.
1. Click the
o
C key to set the dialysate temperature.
