4. TSM Service Program 1/2010 4 - 166
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
5. Set temperature TSD to 37
o
C and wait for the temperature reached.
Note for machines equipped with DF filter:
The DF filter and the tubings going to the DF filter must be free of air before
the DDE can be adjusted. Therefore the machine must be switched into Bypass
for a few minutes to purge the air. Switch off the bypass for the calibration of
DDE as it has to be done in mainflow.
6. Loosen lock nut on DDE adjustment screw.
7. Set a pressure of 300 mmHg/400 mbar with the adjustment screw of DDE.
• 300 mmHg ±37 mmHg
• 400 mbar ±50 mbar
8. Tighten lock nut again.
9. Remove manometer and flow meter.
