7. Spare Parts List 1/2010 7 - 13
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
DF Block
4a
34770925 5 Plug
4b
34770852 5 O-ring 11.1 x 1.6
4c
34771050 10 Pressure spring 500 mmHg
4d
34772928 3 Centre disc
4e
34771085 5 Seal
5a
34570373 10 Plug (long)
5b
3451614B 1 Temperature sensor
without connector
5c
3477104A 10 O-ring 8.3 x 2.4
5a
5b
5c
TSBIC
TSD
FPE
FPA
BICP
UFP
KP
RVB
RVK
BICLF
ENDLF
1a/b
1a/b
2
4b,10 3
4
66 6
55
4a
4e
4c
4d
4b
