Conventions
Symbol Description
Attention
The symbol gives information, which are safety relevant for
the Dialog+ and must be observed.
Information
The symbol gives additional information, which should be
observed.
Tips
The symbol gives additional hints, which can be helpful.
Handling
The symbol gives information for a handling at or in the
machine, i.e. during a calibration, disassembly or assembly.
Calibration
The symbol appears for necessary calibration measures.
Calibration Equipment/Tools
The symbol gives remarks for necessary calibration
equipment/tools, i.e. during a calibration, disassembly or
assembly.
