B. Braun Dialog+ - Page 76

3. Repair Instructions 1/2010 3 - 14
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
6.
1245x
Pressure build-up
VDABK
VDABKVDABK
VDABK
FPE = 500 ml/min
FPA = 100 ml/min
Valve Status:
VEBK1/2, VDEBK1/2, VABK1/2 --------- opened
VDABK1/2 ----------------------------- closed
VBP, VDA, VDE------------------------ opened
PDA
≥
+425
mmHg
for 1 s or timeout 60 s
12101
7.
1250x
Pressure reduction with UFP
FPE = 800 ml/min
FPA = 20 ml/min
Valve Status:
VEBK1/2, VDABK1/2------------------- opened
VDEBK1/2, VABK1/2-------------------- closed
VBP, VDE ----------------------------- opened
VDA----------------------------------- closed
PDA
≤
+380 mmHg or timeout 60 s
12101
8.
1255x
Membrane test
FPE = 800 ml/min
FPA = 20 ml/min
Valve Status:
VEBK1/2, VDABK1/2------------------- opened
VDEBK1/2, VABK1/2-------------------- closed
VBP, VDE, VDA------------------------ opened
Test timeout 60 s or wait for inversion of
LLS_SELFTESTBIT from LLS
Start condition for the test (10 s):
1. Correct valve position
2. UFP stopped (UF rate < 500 ml/h)
3. +300 mmHg < PDA < +450 mmHg
Test 10 s,
max. deviation
∆
PDA < 25 mmHg,
Acknowledge with inversion of LLS_SELFTESTBIT
12101 –
12121
12122 –
12131
12132
12133
9.
1260x
Pressure build-up VABK
FPE = 500 ml/min
FPA = 500 ml/min
Valve Status:
VEBK1/2, VDEBK1/2, VDABK1/2-------- opened
VABK1/2 ------------------------------ closed
VBP, VDA, VDE------------------------ opened
PDA
≥
+425 mmHg for 1 s or timeout 60 s
12151
10.
1265x
Membrane movement
FPE = 500 ml/min
FPA = 1500 ml
⋅
/min
Valve Status:
VEBK1/2, VABK1/2 --------------------- closed
VDEBK1/2, VDABK1/2 ----------------- opened
VBP, VDA, VDE------------------------ opened
Test timeout 60 s or no increase of the values of
the membrane position sensors
12151
11.
1270x
Pressure reduction with UFP
FPE = 500 ml/min
FPA = 500 ml/min
Valve Status:
VEBK1/2, VABK1/2 --------------------- closed
VDEBK1/2, VDABK1/2 ----------------- opened
VBP, VDE ----------------------------- opened
VDA----------------------------------- closed
PDA
≤
+380 mmHg or timeout 60 s
12151
