12-Lead Resting ECG Analysis
9-2
9.4.1 Input Patient Information (For Glasgow Algorithm Only)
Some of the patient information directly affects the result of 12-lead analysis, so it is essential to complete the right
patient information diagnostic and medical treatment. Please input patient information before performing 12 -lead
analysis.
Steps to input patient information are as follows:
1) In the 12-Lead Full-Screen, select [Setup] to enter [12-Lead Setup] menu.
2) Input or edit patient information on the [Patient Information] page.
NOTE
 Prior to 12-lead resting ECG analysis please remember to check the patient information is complete and
correct.
 For pediatric patients below 16 years old it is recommended to place chest leads at V4R, V1, V2, V4-V6.
This is a routine procedure for pediatric patients.
9.4.2 Set the filter
1） On the ECG 12-Lead screen, select [Setup] into [12-Lead] menu.
2） Select [Setup] tab
3） Set [Filter] as: [Diagnostic] or [ST].
After entering the 12-Lead screen, the filter mode is automatically set to [Diagnostic]. When exiting 12-Lead
screen [Filter] reverts to the previous settings before entering 12-Lead screen.
4） Set Tachy and Brady Thresholds (Available for Glasgow Algorithm Only)
1) In the 12-Lead Full-Screen, select [Setup] to enter [12-Lead Setup] menu.
2) Select [Setup] tab.
3) Set [Tachy] and [Brady].
NOTE
 Tachy Threshold is only intended for patients older than 180 days.
 Brady Threshold is only intended for patients older than 2,191 days.
9.4.3 Set 12-Lead Report
1) In the 12-Lead Full-Screen, select [Setup] to enter [12-Lead Setup] menu.
2) Select [Report] tab.
3) Set the format and contents of the 12-Lead Report.
