18.5.1 Access to Pacer View Window
You can use either of the following options to open the Pacer View:
Choose [Pacer View] hot key;
Click the [ECG] menu and choose [Pacer] tab, → [Pacer View]
Click the [Main Menu] hot key →[CCA] tab and choose [Pacer View]
18.5.2 Review the Real-time Pacer
Under the [Pacer View] window, select [Current], tab to check the pacing information in real-time:
Through [Pacer indication] tab access to the pacing pulse interval.
Through [Pacer pulse indication] tab access to the pacer pulse amplitude, width and its shape.
Under the [Pacer View] window you can do the following:
Click [Update] to update the most current pacer pulse information.
Click [Save as Event] to save the current pacing as one history event.
Select [Lead] to check the pacer pulse on the lead you want.
Select to arrow left and right to check the pacer pulse.
18.5.3 Review the History Pacer
You can review the detail information of [Pacer not pacing], [Pacer not capture] and pacer event in history with the
following steps:
Under [Pacer View] window select [Even] tab. See “
27.5.1 Access to Pacer view window”
for details.
Under [ECG 24H Summary] window select the pacer statistic. See
“27.4.3 ECG 24H Summary review”
for
details.
Select one of the events, click [Detailed] to check the pacer pulse and its indication.
You can also check the history of Pacing events through review:
1) Under [Review] window and select [Event] tab.
2) Select one of the events, click [Detailed].
Select [Pacer View].
