Comen N10 - Save Current Settings; Delete Configuration; Export Configurations; Import Configuration

Manage Configuration
6-17
default settings and user settings can be selected under each patient type.
6.5 Save Current Settings
The Current configuration of the monitor can be saved as the user configuration under the current department. Up
to 25 sets of user configurations can be saved for each department. Save Current Settings in the following way:
1) Click [Main Menu] hot key → [Configuration] → [Manage], enter the configuration password and click the
Enter key.
2) Click the [Save Current Settings] button.
3) Input the Configuration Name.
4) Click [OK].
6.6 Delete Configuration
1) Click [Main Menu] hot key → [Configuration] → [Manage], enter the configuration password and click the
Enter key
2) Click the [Delete Configuration] button.
3) Select the settings to be deleted.
 The user settings saved on the monitor and the USB drive are displayed in the [Delete Configuration]
menu.
4) Click the [Delete] button.
6.7 Export Configurations
You can save the current user settings of the monitor to the USB drive as follows:
1) Insert a USB drive into the monitor.
2) Click [Main Menu] hot key → [Configuration] → [Manage], enter the configuration password and click the
Enter key.
3) Click the [Export Configuration] button.
4) Select the settings to be exported.
5) Click [Export].
6.8 Import Configuration
You can import the settings from a USB drive into the monitor as follows:
1) Insert a USB drive with the configuration settings file into the monitor.
2) Click [Main Menu] hot key → [Configuration] → [Manage], enter the configuration password and click the
