Clinical Assistant Assessment (CAA)
17-9
17.9 ST
If the ST Analysis option is enabled the Monitor will save the ST-segment data and waveforms at a 5min interval.
You can go to the ST page to view such data and waveforms.
17.9.1 Go to the ST Page
Follow either path described below to go to the ST page:
 Click [Review] hot key → [ST] tab; or
 Click [Main Menu] hot key → [Review] → [ST].
17.9.2 Set the Reference Template
You can follow the steps below to save the current ST data as the reference template:
1) Go to the ST page;
2) Click [Save Ref.].
NOTE
 The Monitor takes the ST baseline as the reference template by default.
17.9.3 Show/Hide Reference Template
1) Go to the ST page;
2) Click [Show Ref.] or [Hide Ref.].
17.9.4 Show/Hide Markers
1) Go to the ST page;
2) Click [Display Marker] or [Hide Marker].
 [Display Marker]: on the ST template, the ISO point, J point and ST point are marked with white vertical
lines.
 [Hide Marker]: on the ST template, the ISO point, J point and ST point are not displayed.
17.9.5 Print ST-segment Data
1) Go to the ST page;
2) Locate the desired time point;
