IBP Monitoring
14-9
14.5.8 Set IBP Sensor Type
1) Select [Main Menu] hot key → [System] → [Maintenance], enter the maintenance password and click the
Enter key.
2) Select [Module] tab → [IBP] tab.
3) Select [Sensor Type].
14.5.9 Change Pressure Unit
1) Select [Main Menu] hot key → [System] → [Maintenance], enter the maintenance password and click the
Enter key.
2) Select [Unit] tab.
3) Set [Pressure Unit], [CVP Unit] and [ICP Unit].
14.5.10 IBP Overlap
You can display two parameter waveforms in the IBP waveform area as follows:
1) Enter [Tile Layout] in any of the following ways:
 Select [Screen Setup] hot key → select [Tile Layout] tab.
 Select [Main Menu] hot key → [Display] → [Tile Layout].
2) Select [IBP Overlap] in the parameter area and select IBP waveforms to be overlaid on the same line on the
left.
3) Repeat step 2 at other parameter areas as required.
4) Select " " to exit. Then the overlaid IBP waveforms are displayed on the main menu.
Select the overlaid IBP waveform wave on the main screen to enter [IBP Overlap Setup] menu, where you can
choose the following settings:
 Scale
 Set [Left Scale] for arterial pressure.
 Set [Right Scale] for venous pressure.
 Set [CVP Scale] when the overlaid waveforms includes a CVP waveform and the CVP unit is inconsistent
with other pressure units.
 Set [ICP Scale] when the overlaid waveforms include an ICP waveform and the ICP unit is inconsistent with
other pressure units.
 Set [PA Scale] when the overlaid waveforms include a PA waveform.
 Set [Grid] of overlaid waveform area.
 Set [Waveform Speed] of overlaid waveforms.
