16.6.1 Preparations for Measurement
1) Insert the C.O. module into the monitor.
2) Insert the C.O. cable into the C.O. module.
3) Connect the Swan-Ganz catheter, syringe and other components according to the manufacturer’s instructions,
as shown in the figure below:
16.6.2 Measurement Setup
Before C.O. measurement, set as below:
1) Select the C.O. parameter area to enter [C.O.] menu.
2) Select [Setup] tab.
3) Set the parameters according to "
Section 17.5 C.O. Setup
".
Do not touch any conductive metal when an accessory is used.
Select an injection solution volume and computation coefficient for the drift catheter. Enter the
computation coefficient as instructed in the User’s Manual of the drift catheter after replacement.
Use the cable, catheter and probe recommended by the manufacturer only.
