Basic Operations
4-9
4.4.1 Freeze Waveforms
You can select the [Freeze] hot key to freeze active waveforms. Parameter data is refreshed normally.
In the frozen state, the following windows and waveforms are normally displayed and refreshed:
Minitrends Screen
OxyCRG
Remote View Window
Score Window
4.4.2 View Frozen Waveforms
Adjust the “ ” or “ ” button in the [Freeze] menu to view the previous and next frozen waveforms.
The time scale is displayed at the lower right corner the waveform; the freeze moment is flagged as [0s]. With the
rightward movement of the waveform, the time scale will change to [-1s], [-2s], [-3s] ... in sequence, indicating that
the waveform currently displayed is the waveform content N second(s) before the freeze moment. This time scale
applies to all frozen waveforms on the screen.
4.4.3 Unfreeze
Select “ ” at the upper right corner of the [Freeze] menu to unfreeze the waveforms.
4.4.4 Print Frozen Waveforms
Select “ ” at the upper left corner of the [Freeze] menu; the printer will print the waveforms displayed on the
current screen and all parameter values at the freeze moment.
4.5 Use of Timers
This monitor can simultaneously display a maximum of 4 timers. You can respectively set each timer which will give
a prompt when the set times have been completed.
