TEMP Monitoring
13-2
3) Place the temperature sensor on the measurement site reliably.
4) Set the temperature sensor type; please refer to “
Section 13.5.3 Set Temp Type
” for more information.
Before temperature measurement ensure that the temperature probe cable is in good condition. Remove
the temperature sensor cable from connector, and the monitor displays the prompt message [T1 (T2) sensor
off] and triggers an audio alarm.
Handle the temperature probe and cable with caution. When they are not in use, coil them loosely. Tight
coiling may cause mechanical damage to the cable.
Calibrate the Temperature at least every two years or as required by the hospital’s regulations. Contact the
manufacturer for calibration when necessary.
The Temperature probe is the direct mode.
The intended measurement site includes but is not limited to: skin surface, axilla arterial, rectal,
esophageal,.
To obtain accurate measurements the recommended minimum measurement time for surface
temperature probe is 180s, for cavity temperature probe is 150s.
The transit response time is not in excess of 40s.
13.5 Temperature Setup
13.5.1 Set Temperature Alarm
1) Select the temperature parameter area to enter [TEMP] menu.
2) Select [Alarm] tab.
3) Set the alarm as required.
13.5.2 Display Temp Difference
The user is required to turn on the temperature difference switch to display the difference of two TEMP values (ΔT).
The steps are as follows:
1) Select the TEMP parameter area to enter [Temp] menu
2) Select [Setup] tab.
