Basic Operations
4-7
4.3.4 Set Layout of the Large Fonts Screen
You can select parameters and waveforms to be displayed and their positions in the large-font screen as shown
below:
1) Enter the [Large Fonts] tab in either of the following ways:
Select the [Screen Setup] hot key → select the [Large Fonts] tab; or
Select the [Main Menu] hot key → select [Tile Layout] from the [Display] column → select the [Large
Fonts] tab.
2) Select each area; select the parameters to be displayed in this area from the pop-up parameter list. All selected
parameters and waveforms will be displayed according to the set positions; parameters and waveforms not
selected will not be displayed on the screen.
4.3.5 Set the Language
1) Select [Main Menu] → select [Maintenance] from the [System] column → input the maintenance password
→ press the Enter key.
2) Select [Other] → select [Language], and select the language as required.
3) Reboot the monitor to put the language selected into effect.
4.3.6 Date and Time
1) Select [Main Menu] → select [Time] from the [System] column.
2) Select [Date] and [Time] to set the current date and time.
3) Set [Date Format].
4) If 12-hour time is required, turn off [24-Hour Time].
When the monitor is connected to the central monitoring system, the system time of the monitor will be
synchronous with that of the central monitoring system, and you cannot set the system time of the monitor.
4.3.7 Set Brightness
1) You can enter the [Display] page in either of the following ways:
Select the [Screen Setup] hot key → select [Display].
Select the [Main Menu] hot key → select [Display] from the [Display] column.
2) If the monitor is using the AC power supply, set [Brightness]; if the battery is used to supply voltage, set
[Brightness On Battery].
