Clinical Assistant Assessment (CAA)
17-10
3) Click " ".
17.10 Minitrends
The Minitrends window is located in the left of the waveform area and displays the trends of a series of parameters
in the most recent period. If the Monitor is integrated with an external device, you can also view the Minitrends of
the external device in the Minitrends window.
17.10.1 Go to the Minitrends Page
Follow any path described below to go to the Minitrends page:
Click [Minitrends] hot key;
Click [Screen Setup] hot key → [Minitrends]; or
Click [Main Menu] hot key → [Display] → [Choose Screen] → [Minitrends].
In the Minitrends window, the corresponding parameter name is displayed above each trend curve and the trend
scale is displayed on the left.
17.10.2 Select the Parameters to be Reviewed
1) Go to the [Minitrends] page;
2) Click the Minitrends area to go to the [Trend Setup] menu;
3) Select the desired parameters. If you want to select the default parameters, select [Default Parameters].
17.10.3 Set the Trend Time
1) Go to the [Minitrends] page;
2) Click the Minitrends area to go to the [Trend Setup] menu;
3) Set the [Trend Time].
17.10.4 Exit the Minitrends Page
Follow either path described below to exit the Minitrends page:
Click [Screen Setup] hot key and select the page you want to enter; or
Click [Main Menu] hot key → [Display] → [Choose Screen] and select the page you want to enter.
Slide the current screen with two fingers to access other screens.
