14.5.4 Display Pressure Type
If the current pressure is an expansion pressure (P1, P2, P3 or P4) you can select the pressure type displayed in the
parameter area by the following method:
1) Select the expansion pressure parameter area or waveform area to enter the corresponding pressure menu.
2) Select [Setup] tab.
3) Select [Measure]:
If the current expansion pressure is arterial pressure, you can set [Measure] to [All], and then the
parameter area corresponding to the pressure shows all the pressures: SYS, DIA, and MEAN.
If the current expansion pressure is venous pressure, you can set [Measure] to [Mean Only], and then
only MEAN is displayed in the parameter area corresponding to the pressure.
14.5.5 Set IBP Waveform Speed
1) Select the IBP parameter area or waveform area to enter the corresponding pressure menu.
2) Select [Setup] tab.
3) Set [Waveform Speed].
14.5.6 Set IBP Scale
1) Select the IBP parameter area or waveform area to enter the corresponding pressure menu.
2) Select [Setup] tab.
3) Set [Scale]: if [Auto] is selected the upper and lower scales of IBP waveform will automatically change according
to the wave amplitude; if [Manual] is selected, set [Upper Scale] and [Lower Scale] respectively.
14.5.7 Set Alarm Limits Display
1) Select the IBP parameter area or waveform area to enter the corresponding pressure menu.
2) Select [Setup] tab.
3) Turn on the [Display Alarm Limits] switch as required
