RESP Monitoring
10-4
10.5.4 Set Resp Lead
RESP lead indicates the source of the current RESP waveform. If you select [Auto] the monitor will automatically
select an appropriate respiration lead.
1) Select the respiration parameter area or waveform area to enter [Resp] menu.
2) Select [Setup] tab.
3) Set [Resp Lead]
If the respiration waveform is still poor or you suspect that the RR measurement is inaccurate after Resp lead
adjustment, you can adjust the position of the electrodes.
10.5.5 Set Gain
Gain is used to adjust the amplitude of the respiration waveform. Steps to set gain are as follows:
1) Select the respiration parameter area or waveform area to enter [Resp] menu.
2) Select [Setup] tab.
3) Set [Gain].
10.5.6 Set Waveform Speed
1) Select the respiration parameter area or waveform area to enter [Resp] menu.
2) Select [Setup] tab.
3) Set [Waveform Speed].
10.5.7 Set Filter
Filter is designed to filter out the Resp interference. Steps to set filter are as follows:
1) Select the respiration parameter area or waveform area to enter [Resp menu.
2) Select [Setup] tab.
3) Set [Filter] to [On] or [Off].
10.5.8 Set Auto Threshold Detection
1) Select the RESP parameter area or waveform area to enter [Resp] menu.
2) Select [Setup] tab.
3) Turn on or off [Auto Threshold Detection].
 ON: the monitor automatically adjusts the detection level of Resp wave, i.e. detection threshold.
 OFF: you need to manually adjust the detection threshold of Resp wave; please refer to " Section10.5.9
Manually Adjust Detection Threshold " for more information.
