Clinical Assistant Assessment (CAA)
17-7
17.7.2 Select Compressed Waveforms
To review compressed waveforms you must first follow the steps below to select the parameter waveforms to be
stored and displayed:
1) Go to the Full-Disclosure Waveforms page;
2) Click [Setup] tab and select the waveforms to be stored;
3) Click [Waveform] and select the stored waveforms to be displayed.
If you select a large number of waveforms to be stored, they will be stored for a short time (probably
less than 48h) due to the limited memory size. Please control the number of waveforms to be stored.
When an alarm occurs the wave band at the alarm time (on the compressed waveform) will be displayed on a
colored background, depending on the Alarm Priority.
Red: high-priority alarm.
Yellow: medium-priority alarm.
Cyan: low-priority alarm.
17.7.3 View Details of Compressed Waveforms
Follow the steps below to view the full version and parameter values of the compressed waveforms:
1) Go to the Full-Disclosure Waveforms page;
2) Click the desired compressed waveform area to display the details above such area.
17.7.4 Set the Waveform Gain of Details Area
1) Go to the [Full Disclosure] page;
2) Set the [Gain].
17.7.5 Print the Full-Disclosure Waveforms Report
1) Go to the [Full Disclosure] page;
Click " ", set the time length of the waveform to be printed and click [Print].
