Record
20-3
Click [Alarm Setup] hot key;
Click the corresponding parameter area or waveform area → [Alarm] tab; or
Click [Parameters Setup] hot key, select the desired parameter and then click [Alarm] tab.
2) Enable [Alarm Output].
20.6 Clear Record Task
1) Click [Main Menu] hot key → [Report] → [Record Setup].
2) Click [Clear Record Task] to clear all reports to be output and to stop the current recording task.
20.7 Load Recording Paper
1) Use the latch on the recorder door to pull the door open.
2) Remove the empty paper core to load a new roll paper. .
3) Close the recorder door upwards and close it tightly until a ‘click’ sound is heard.
4) Start recording in order to check whether the paper is loaded correctly.
5) If the printing process fails to be initiated, the paper may have been loaded upside down. Try to reload the
paper.
Load paper carefully; otherwise the thermal print head may get damaged.
During output by the recorder, it is not allowed to pull the record paper outward with force; otherwise
the recorder may get damaged.
Do not keep the recorder door open except for paper change or troubleshooting.
20.8 Clear Jammed Paper
Isf the recorder makes any abnormal sound during operation or the record paper outputs abnormally, please check
to see if any paper is jammed. If yes, please clear it according to the following steps:
1) Open the recorder door.
2) Take out the record paper, and cut off the creased part.
3) Reload the record paper, and close the recorder door.
20.9 Recorder Cleaning
After long-term use of the recorder, scraps of paper and impurities will be accumulated on the print head which
will affect the quality of recording and the service life of print head and roll shaft.
Cleaning:
