ECG Monitoring
8-12
8.4.8.8 Set Heart Beat Marker
User can set whether to display the heart beat marker (N indicates normal heart beat; A for abnormal heart beat
and P for pacing heartbeat) above the ECG waveform. Steps are as follows:
1) Click on ECG parameter area or waveform area to enter [ECG] menu.
2) Select [Setup] tab.
3) Set [Smart Lead] to [ON] or [OFF]
8.4.9 Set Smart Lead Off
The smart lead off is set to [ON]: If the lead of the first primary waveform falls off, the screen will automatically
switch to other waveform with good ECG signal quality, and recalculate the heart rate and arrhythmia analysis. If
the fallen lead is connected again, the screen will automatically switch to the previous lead.
1) Select the ECG parameter area or waveform area to enter [ECG] menu.
2) Select [Setup] tab.
3) Set [Smart Lead] to [ON] or [OFF].
8.4.10 Set Lead Off Alarm Priority
1) Select [Main Menu] hot key → [System] → [Maintenance], enter the maintenance password and click the
Enter key.
2) Select [Alarm] tab → [Other] tab.
3) Set [ECG Lead Off].
8.5 Arrhythmia Analysis
Arrhythmia analysis is intended for adult, pediatric and neonate patients.
8.5.1 Safety Information on Arrhythmia
Arrhythmia may affect the heart rate. During monitoring of patients with arrhythmia do not completely
rely on the alarm function of the cardiotachometer, and patients with arrhythmia should be closely
monitored.
The arrhythmia analysis is not intended to replace traditional methods of diagnostic or treatment.
It is not expected that the critical care clinicians rely heavily upon information provided by the
