Comen N10 - Set Signal IQ (Not for Nellcor Spo ); Display PI (Not for Nellcor Spo ); PR Setup; Set PR Alarm

NIBP Monitoring
11-13
To set [Smart Tone]:
1) Select the SpO
2
parameter area to enter [SpO
2
] menu.
2) Turn on or off [Smart Tone].
11.8.10 Set Signal IQ (Not for Nellcor SpO
2
)
The magnitude of the SpO
2
SIQ waveform provides an assessment of the confidence in the measurement. A higher
value indicates higher confidence in the measurement whereas a smaller value indicates lower confidence.
Movements usually affect the signal quality. When the arterial pulse reaches the peak, the monitor marks its
location on the vertical line (signal indicator). The height of the vertical line represents the quality of the measured
signal (the higher line, the higher quality). Set [Signal IQ]:
1) Select the SpO
2
parameter area or waveform area to enter [SpO
2
] menu.
2) Select [Setup] tab.
3) Turn on or off [Signal IQ].
11.8.11 Display PI (Not for Nellcor SpO
2
)
[Display PI] defaults to [On]. Steps to set it to Off:
1) Select the SpO
2
parameter area or waveform area to enter [SpO
2
] menu.
2) Select [Setup] tab.
3) Set [Display PI] to [Off].
11.9 PR Setup
11.9.1 Set PR Alarm
You can set the PR alarm in the following way:
1) Select the SpO
2
parameter area or waveform area to enter [SpO
2
] menu.
2) Select [PR] tab → [Alarm] tab.
3) Set the alarm as required.
11.9.2 Set PR Source
The color of the PR parameter area is the same as the display color of PR source parameters.
You can set the PR source in the following way:
1) Select the SpO
2
parameter area or waveform area to enter [SpO
2
] menu.
2) Select [PR] tab → [Setup] tab.
