ECG 24H Summary only applies to the current patient, not historical patients.
Pacer statistics only apply to patients wearing pacemakers.
The ECG summary report is designed to store, count and centrally display the realtime data measured
by the Monitor.
The access to ECG 24H Summary review function requires a License.
18.4.1 Go to the ECG 24H Summary Window
Click [Main Menu] hot key → [CAA] → [ECG 24H Summary].
18.4.2 Select Typical ECG Waveforms
The typical ECG waveforms under the following conditions are displayed in the Typical ECG Waveforms area:
Maximum HR value;
Minimum HR value;
Four arrhythmia alarm events.
You can select a typical ECG waveform under each condition. For example, to select the typical ECG waveform of
arrhythmia alarm, please:
1) Click the current ECG waveform of arrhythmia alarm;
2) Select a typical ECG waveform of arrhythmia alarm from the arrhythmia alarm events during the last 24h.
18.4.3 ECG 24H Summary Review
On the [ECG 24H Summary] window, you can review various ECG data:
Click [Full Disclosure] to review Full-Disclosure waveforms (refer to “
Section 17.7 Full-Disclosure waveforms”)
for
more information
18.5 Pacer View
For patients with pacer, the monitor provides a Pacer View to review the detailed information about pacing,
including the pacer pulse width, amplitude and period.
