Comen N10 - Place 5-Lead Electrodes

ECG Monitoring
8-5
8.3.3.2 Place 5-lead Electrodes
Refer to American and European standards for placing electrodes of a 5-lead unit:
White/red (right arm) electrode — Place it below the clavicle, near the right arm.
Black/yellow (left arm) electrode — Place it below the clavicle, near the left arm.
Green/black (right leg) electrode — Place it at the right lower abdomen.
Red/green (left leg) electrode — Place it at the left lower abdomen.
Brown/white (chest) electrode — Place it on the chest wall.
RA White (U.S.A.)
R Red (EU)
LA Black (U.S.A.)
L Yellow (EU)
LL Red (U.S.A.)
F Green (EU)
Lewis
RA White (U.S.A.)
R Red (EU)
LA Black (U.S.A.)
L Yellow (EU)
LL Red (U.S.A.)
F Green (EU)
Lewis
