Clinical Assistant Assessment (CAA)
17-8
17.8 12-Lead Report Review
On the 12-Lead Report Review page, you can review the last 20 12-lead ECG events and their analysis and diagnosis
results. See “
Section 9 12-Lead Resting ECG Analysis”
for more 12-lead ECG information.
17.8.1 Go to the 12-Lead ECG Page
Follow any path described below to go to the 12-Lead ECG page:
When the 12-lead ECG analysis is completed, click [Review] in the [12-Lead Resting ECG Results] window;
Click [Review] hot key → [12-Lead ECG] tab; or
Click [Main Menu] hot key → [Review] → [12-Lead ECG].
17.8.2 View the Average Template
On the average template waveform of each lead, the starting position and ending position of the P wave and QRS
wave and the ending position of the T wave are marked with short vertical lines. When the average template is
displayed, a rhythm lead waveform will be displayed on the page. Follow the steps below to view the average
template:
1) Go to the [12-Lead ECG] page;
2) Click [Average Template].
On this page, you can click [Waveform] to return to the [12-Lead ECG] page.
17.8.3 Set the Waveform Displayed in 12-Lead ECG Page
1) Go to the [12-Lead ECG] page;
2) Click [Waveform Speed] to change the sweep speed of the ECG waveform;
3) Click [Gain] to change the gain of the ECG waveform;
4) Click [Layout] to change the layout of the ECG waveform.
17.8.4 Print the 12-Lead ECG Report
Follow the steps below to print the 12-lead ECG report:
1) Go to the [12-Lead ECG] page;
2) Click " " or " " to print the 12-lead ECG report.
