ECG Monitoring
8-8
8.4 ECG Setup
8.4.1 Set the ECG Lead Type
1) Select the ECG parameter area or waveform area to enter [ECG] menu.
2) Select [Setup] tab.
3) Set [Lead Type] based on the lead used. If [Auto] is selected, the Monitor will automatically detect the type of
ECG lead connected.
8.4.2 Check Pacer Status
It is very important to set the patient's pacer status correctly before ECG monitoring. If the [Pacer] is set to [Yes]
and pacing signal is detected, " " will be shown above the ECG waveform, and will be shown in the ECG
waveform area; if the [Pacer] is set to [No], there will be no icon or symbol displayed.
Steps to set the pacers status:
1) Select the ECG parameter area or waveform area to enter [ECG] menu.
2) Select [Pacer] tab.
3) Set [Pacer] to [Yes] or [No].
If the pacer status is set to [No] the Monitor will give a voice prompt, the icon will flash in the ECG waveform
area and the message [Please confirm whether the patient has a pacer] will be displayed when a pacing signal is
detected.
8.4.3 Set Pacer Reject
The Monitor is designed with the function of rejecting the display of a pacing signal, the method for setting pacer
reject is as follows:
1) Select the ECG parameter area or waveform area to enter [ECG] menu.
2) Select [Pacer] tab.
3) Set [Pacer Reject] to ON or OFF.
NOTE
 The setting of [Pacer Reject] will not affect the display of pacemaker pulse symbol " ", and the
prompt message of “Pacer Reject off” will be displayed in the technical alarm area.
 You can set [Pacer Reject] only if [Pacer] is set to [Yes].
