Calculation
19-3
19.4 Hemodynamic Calculation
19.4.1 Calculation Steps
1) Follow either step described below to go to the Hemodynamic page:
 Click [Calculations] hot key → [Hemodynamic] tab; or
 Click [Main Menu] hot key → [Calculations] → [Hemodynamic].
2) Enter the correct value of each parameter. For the patient being monitored the Monitor will take the measured
value as the input value and import the height and weight value from the entered patient information.
3) Click [Calculate] to calculate the value of each output parameter.
On the Hemodynamic page you can also perform the following operations:
 Click [Range] to display the normal range of each parameter. Then you can check whether the calculation
results fall within the normal range.
 Click [Unit] to display the unit of each parameter.
19.4.2 Input Parameters
Abbreviation
Unit
Full Name
HR
bpm
Heart rate
C.O.
l/min
Cardiac output
PAWP
mmHg
Pulmonary artery wedge pressure
MAP
mmHg
Artery mean pressure
MPAP
mmHg
Pulmonary artery mean pressure
CVP
mmHg
Central venous pressure
EDV
ml
End-diastolic volume
Height
cm
Height
Weight
kg
Weight
19.4.3 Output Parameters
Abbreviation
Unit
Full Name
C.I.
l/min/m
2
Cardiac index
BSA
m
2
Body surface area
