Alarms
7-9
7.9.9 Alarm Audio Off
If [Pause Time] is set to [Permanent] (refer to "
Section 7.9.3 Set alarm pause time
"), the [Alarm Audio Paused]
hot key is changed to [Alarm Audio off] key. All alarm audio will be muted if [Alarm Audio Paused] hot key is pressed.
Alarm audio off characteristics:
The alarm audio of physiological alarms and technical alarms will be cancelled.
The alarm audio off icon will be displayed in the message area.
Click this hot key again to exit the alarm sound off status.
Risk may exist if the alarm audio is paused or turned off. The user should pay close attention to the
actual clinical conditions of patients.
7.10 Set SpO
2
Desat Alarm (Not for Rainbow SpO
2
)
1) Click [Main Menu] hot key → [System] → [Maintenance], enter the maintenance password and click the Enter
key.
2) Select [Alarm] tab → [Other] tab.
3) Set [SpO
2
Desat Alarm Off]:
[Disable]: SpO
2
desat alarm will be kept on, and cannot be turned off.
[Enable]: SpO
2
desat alarm can be turned off.
7.11 Set the Switch Status of Apnea Alarm
1) Click [Main Menu] → [System] → [Maintenance], then enter the maintenance password and click the Enter
key.
2) Select [Module] tab → [Other] tab.
3) Select [Apnea Alarm Off]:
when [Disable] is selected：the [Apnea Alarm] is in its working state, thus any apnea alarms triggered
cannot be switched off.
when [Enable] is selected：the apnea alarms triggered can be switched off.
7.12 Set the Switch Status of CMS Disconnection Alarm
If the monitor is expected to alarm upon disconnecting from the Central Monitoring System (CMS) , user is allowed
to set the switch status by following steps:
1) Select [Main Menu] →[System]--- [Maintenance]→input password→click Enter key
