Clinical Assistant Assessment (CAA)
17-11
17.11 OxyCRG
Follow either path described below to go to the OxyCRG screen:
Click [Screen Setup] hot key → [OxyCRG]; or
Click [Main Menu] hot key → [Display] → [Choose Screen] → [OxyCRG].
Two trend curves and one compressed waveform are displayed on the OxyCRG screen.
17.11.1 Select Parameters and Scale
1) Go to the [OxyCRG] screen;
2) Click [Setup];
3) Set [Trend1], [Trend2] and [Compressed Waveforms] respectively;
4) Click [Scale] tab and set the scale of each parameter.
17.11.2 Set the Window Time
1) Go to the [OxyCRG] screen;
2) Set [Zoom] to [1min], [2min], [4min] or [8min].
17.12 Close Unnecessary Review Items
You can follow the steps below to close the unnecessary review items:
1) Click [Main Menu] → [System] → [Maintenance], enter the maintenance password and click the Enter key;
2) Click [Review] tab;
Click [Page] tab and uncheck the unnecessary review items.
