Compulite Spark User Manual

Spot Parameters
Spark
6-9
Assigning values for discrete steps
Discrete parameters are composed of steps, which increment by one step at a time.
Example: Gobo wheels are usually discrete step parameters, enabling easy selection of
each gobo. Martin PAL’s static gobo wheel is defined as an 11 step discrete parameter.
When using the parameter wheel to assign the gobo, the gobo wheel moves from gobo to
gobo, with no stops in between.
Discrete parameters are displayed as a single digit preceded by an icon. Thus step 1 is
displayed like this:
1
. Step 11, like this:
1
.
Discrete parameter values may be assigned using the wheel, the SKs, the numeric keypad,
and [STEP UP] or [STEP DN].
Assigning a discrete step value using the Step keys
Example: Martin PAL’s gobo wheel (param 6) is selected. You want to assign step 2.
Keypresses Results/Comments
1. Select spots. The controller SK display shows the
parameter selections. If you do not see the
parameter display, press
[PARAM]
.
2. Press the SK for parameter
selection.
3. Press
[STEP UP]
or
[STEP DN]
Each press on these keys either
increments or decrements the current
value by 1 step.
Assigning a value to a discrete step using the numeric keypad
Example: Martin PAL’s gobo wheel (param 6) is selected. You want to assign step 2.
Keypresses Results/Comments
1. Select spots. The controller SK display shows the
parameter selections. If you do not see the
parameter display, press
[PARAM]
.
2. Press the SK for parameter
selection.
3. Press
[2]
on the numeric keypad.
Enter a double digit if there are more than
9 steps. Example: for step 1 press 01.
