fo Forward only:
0: Forward and backward movement is processed.
1: Only forward movement is processed.
If the movement of the reference input (master axis) is going backwards, the last forward directed position is kept. The
further forward movement is started when the last seen forward position of the reference input is reached again. If the
guide value goes back more than half of the range, the servo drive goes into fault state.
vel Use velocity:
0: Servo drive calculates the velocity from position dierences internally.
1: Servo drive uses Velocity guide value object (0x2064).
ce Command error:
0: Plausibility check disabled.
1: Plausibility check enable.
7.8.4 Parameter: Guide Value Scaling Factor (0x3808)
The servo drive also supports scaling of the guide value. The scaling factor consists of a numerator and a denominator.
The value 0x0000 0000 must be reserved and not used for the numerator and the denominator objects. To be able to
change both values simultaneously, a writing order is dened. The activation of the new factor is done after the writing of
the numerator. This means to change both values at the same time, the denominator must be written rst and the
numerator afterwards. It is also possible to only change the numerator by writing a new value (the denominator stays the
same). The numerator and denominator accept negative values. The division of 2 negative values results in a positive value.
The Position guide value is multiplied by the quotient of numerator and denominator.
Guide value scaled = (Guide value x Scaling value) + Guide value oset
Internally used 0x2060 0x38060x3808.01/02
Attribute Value
Index 0x3808
Name Guide value scaling factor
Object code Array
Data type INTEGER32
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range UNSIGNED8
Default value 0x02
Sub-index 0x01
LCP parameter number –
Description Guide value scaling numerator
Access Read/write
PDO mapping Optional
Value range INTEGER32
Default value 1
Sub-index 0x02
LCP parameter number –
Description Guide value scaling denominator
Access Read/write
PDO mapping Optional
Value range INTEGER32
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 267
7 7
