Danfoss VLT series Programming Guide

Attribute Value
Description CAM prole memory layout set
Access Read/write
Data type UNSIGNED16
PDO mapping Optional
Value range 2 or 8
Default value 8
Sub-index 0x02
LCP parameter number –
Description CAM prole memory layout act
Access Read only
Data type UNSIGNED16
PDO mapping Optional
Value range 2 or 8
Default value 8
Table 7.126 0x380F: CAM Prole Memory Layout
7.14.2 Parameter: CAM Status (0x3801)
See chapter 2.4.5.7 Notications from the Servo Drive for the description of this object.
Attribute Value
Index 0x3801
Name CAM status
Object code Array
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x04
Default value 0x04
Sub-index 0x01
LCP parameter number –
Description CAM status code
Access Read only
Data type UNSIGNED16
PDO mapping Optional
Value range See Table 2.56 in chapter 2.4.5.7 Notications from the Servo Drive.
Default value –
Sub-index 0x02
LCP parameter number –
Description CAM status parameter 1
Access Read only
Data type UNSIGNED16
PDO mapping Optional
Value range See Table 2.56 in chapter 2.4.5.7 Notications from the Servo Drive.
Default value –
Sub-index 0x03
LCP parameter number –
Description CAM status parameter 2
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 289
7 7
