Danfoss VLT series Programming Guide

Attribute Value
Default value 50 ms
Table 7.118 0x2051: Torque Window Time
7.13 Homing Mode Objects
7.13.1 Parameter 52-40: Home Oset (0x607C)
This object indicates the congured dierence between the zero position for the application and the machine home
position (found during homing). During homing, the machine home position is found and once the homing is completed,
the zero position is oset from the home position by adding the home oset to the home position.
The zero position is calculated as:
zero position = home position + home
oset (see Illustration 7.4).
130BF216.10
Zero
position
Home
position
Home oset
Illustration 7.4 Home Oset Denition
All subsequent absolute moves are taken relative to this new zero position. The value of this object is given in user-dened
position units. Negative values indicate the opposite direction.
Attribute Value
Index 0x607C
LCP parameter number 52-40
Name Home oset
Object code Var
Data type INTEGER32
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range INTEGER32
Default value 0
Table 7.119 0x607C: Home Oset
7.13.2 Parameter 52-41: Homing Method (0x6098)
This object indicates the congured homing method to be used. All supported homing methods can be written into this
object.
Attribute Value
Index 0x6098
LCP parameter number 52-41
Name Homing method
Object code Var
Data type INTEGER8
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 283
7 7
