Danfoss VLT series Programming Guide

9.3.3 Trace Signals
Signal ID (hex) Signal name
PLC library -
trace constant name
Description OD object
00000015 DC-link voltage SAB_TRC_V_DC DC-link voltage 0x 2003
0000003D Warning code SAB_TRC_WARNING Warning code 0x 5FFE
0000003E Error code SAB_TRC_ERROR Error code 0x 603F
0000005A Temperature control card – Temperature control card 0x 2000.2
0000005B Temperature power card – Temperature power card 0x 2000.1
0000005C Temperature SAB card – Temperature SAB card 0x 2000.3
00004019 External encoder position SAB_TRC_EXT_ENC_POSITION External encoder position 0x 2011.1
0000401A External encoder speed SAB_TRC_EXT_ENC_SPEED External encoder speed 0x 2011.2
0000404D UDC 1 current SAB_TRC_I_DC_LINE_1 Current ow on DC link line 1 0x 2001.2
0000404E UDC 2 current SAB_TRC_I_DC_LINE_2 Current ow on DC link line 2 0x 2001.3
0000404F AUX line 1 current SAB_TRC_I_AUX_LINE_1 Current on AUX Line 1 0x 2003.2
00004050 AUX line 2 current SAB_TRC_I_AUX_LINE_2 Current on AUX Line 2 0x 2003.3
00004051 AUX line voltage SAB_TRC_UAUX AUX line voltage 0x 2003.1
00004052 Brake Chopper Gate SAB_TRC_BRAKE_CH_GATE Brake chopper gate –
00004053 Brake Chopper Feedback SAB_TRC_BRAKE_CH_FEEDB Brake chopper feedback –
00007D00 UDC Over-Inrush SAB_TRC_I_INRUSH UDC current over-inrush 0x 2002.5
00007D01 UDC Bypass-Inrush SAB_TRC_I_NORMAL UDC current bypass-inrush 0x 2002.6
00007D02 UDC Back Current SAB_TRC_I_BACK Current (link voltage) back from drives 0x 2002.7
00007D03 Inrush relay power card SAB_TRC_INRUSH_RELAY_PC Inrush relay power card –
00007D04 Inrush relay SAB card SAB_TRC_INRUSH_RELAY_SC Inrush relay SAB card –
00007D05 DC leakage current SAB_TRC_I_DC_LEAKAGE DC leakage current 0x 2001.5
00007D06 Brake resistor power monitoring SAB_TRC_BRAKE_PWR_MON Brake resistor power monitoring 0x 2033
00007D07 DC link total current SAB_TRC_I_DC_SUM DC link total current 0x 2001.1
00007D08 DC link total current raw SAB_TRC_I_DC_SUM_RAW DC link total current (unltered)
00007D09 UDC 1 ow (ltered) SAB_TRC_I_DC_LINE_1_FILT Current ow on DC link line 1 (ltered) 0x 2001.7
00007D0A UDC 2 ow (ltered) SAB_TRC_I_DC_LINE_2_FILT Current ow on DC link line 2 (ltered) 0x 2001.8
80000012 Controlword SAB_TRC_CONTROLWORD Controlword 0x 6040
80000013 Statusword SAB_TRC_STATUSWORD Statusword 0x 6041
80010025 Position guide value reference SAB_TRC_POS_GUIDE_REF Position guide value reference 0x 2062
80010026 Velocity guide value reference SAB_TRC_VEL_GUIDE_REF Velocity guide value reference 0x 2065
Table 9.6 Trace Signals for SAB
Diagnostics Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 377
