Code Name Severity
(Warning/
error/trip
lock)
Description LCP name
0x7182 Brake resistor power limit Error Brake resistor power limit exceeded.
The power transmitted to the brake
resistor is calculated as an average
value over the last 120 s of run time.
The calculation is based on the DC-link
voltage and the brake resistor value set
in parameter 2-16 (Brake resistor power
120 s). The error is reported when the
value is exceeded within 120 s.
brake r pwr lim
0x7183 Brake chopper check failed Error Brake check failed. The brake resistor is
not connected or not working.
brake ch check
0x7380 External position sensor error Error External encoder data could not be
read.
ext sensor err
0xFF21 Internal fan fault Warning Internal fan fault. The fan warning
function checks if the fan is running/
mounted.
fan fault
0xFF31 AUX Line 1 min o time Warning The minimum o time required to
protect the internal hardware has not
been met.
AUX1 min o
0xFF32 AUX Line 2 min o time Warning The minimum o time required to
protect the internal hardware has not
been met.
AUX2 min o
0xFF51 Internal error 1 Trip lock Internal error 1, contact Danfoss. PM int err 1
0xFF52 Internal error 2 Trip lock Internal error 2, contact Danfoss. PM int err 2
0xFF53 Internal error 3 Trip lock Internal error 3, contact Danfoss. PM int err 3
0xFF54 Internal error 4 Trip lock Internal error 4, contact Danfoss. PM int err 4
0xFF55 Internal error 5 Trip lock Internal error 5, contact Danfoss. PM int err 5
0xFF56 Internal error 6 Trip lock Internal error 6, contact Danfoss. PM int err 6
0xFF70 Firmware: Package description
mismatch
Trip lock Firmware found does not match
package description.
FW pack err
0xFF71 Firmware: Power cycle
needed
Warning,
error
Firmware update transfer is completed
but a power cycle is required before
the new rmware is active.
need powercycle
0xFF72 Firmware: Update started Warning,
error
Firmware update in progress. The
warning becomes an error when an
attempt is made to enable the drive in
this state.
FW update
Table 9.5 Error Codes for SAB
Diagnostics
VLT
®
Integrated Servo Drive ISD
®
510 System
376 Danfoss A/S © 01/2017 All rights reserved. MG36D102
99
