Danfoss VLT series Programming Guide

Attribute Value
LCP parameter number 16-10
Access Read only
PDO mapping Yes
Unit Watt
Table 8.11 Object 0x2008: ISD Power Consumption
8.7 Object 0x2009: Fan Speed Power Card
This object shows the speed of the fan on the power card
as a percentage value (0–100%).
Attribute Value
Index 0x2009
Description Fan speed power card
Object code Var
Data type UNSIGNED16
Unit %
Sub-index 0x00
LCP parameter number 51-61
Access Read only
Value range 0–100
PDO mapping Yes
Table 8.12 Object 0x2009: Fan Speed Power Card
8.8
Object 0x200D: Relay 1 Control
This object congures the function of relay 1 with the on
and o delay times. The valid conguration values are
detailed in Table 3.2 in chapter 3.2.1 Relay Outputs.
Attribute Value
Index 0x200D
Description Relay 1 Cong
Object code Record
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x03
Default value 0x03
Sub-index 0x01
LCP parameter number 05-40
Description Relay 1 Cong
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Value range See Table 3.2 in chapter 3.2.1 Relay
Outputs.
Default value 0
Attribute Value
Sub-index 0x02
LCP parameter number 05-41
Description Relay 1 on delay
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Unit Seconds
Value range 0–600
Default value 0
Sub-index 0x03
LCP parameter number 05-42
Description Relay 1 o delay
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Unit Seconds
Value range 0–600
Default value 0
Table 8.13 Object 0x200D: Relay 1 Control
8.9
Object 0x200E: Relay 2 Control
This object congures the function of relay 2 with the on
and o delay times. The valid conguration values are
detailed in Table 3.2 in chapter 3.2.1 Relay Outputs.
Attribute Value
Index 0x200E
Description Relay 2 Cong
Object code Record
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x03
Default value 0x03
Sub-index 0x01
LCP parameter number 05-40
Description Relay 2 Cong
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Value range See Table 3.2 in chapter 3.2.1 Relay
Outputs.
Default value 0
Sub-index 0x02
LCP parameter number 05-41
SAB Parameter Description Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 361
8 8
