Danfoss VLT series Programming Guide

Attribute Value
Value range UNSIGNED16
Default value 0
Table 7.235 0x2FFF: Digital Output Conguration
Value Denition
0 Always o.
1 Always on.
2 Control over Controlword (manufacturer-specic, bit 12).
3 Control over Digital CAM Switch.
4 Control over CAM mode.
Table 7.236 Denition of Values for Digital Output Conguration
7.21.6 External Encoder Objects
7.21.6.1 Parameters 51-30 and 51-34 to 51-40: External Encoder Conguration (0x3000)
These objects congure the external encoder hardware.
Attribute Value
Index 0x3000
Name External encoder cong
Object code Array
Data type Unsigned8
Sub-index 0x00
Description Value of highest sub-index
Access Read only
PDO mapping No
Default value 0x08
Sub-index 0x01
LCP parameter number 51-34
Description External encoder multi-turn bits
Access Read/write
Data type UNSIGNED16
PDO mapping Optional
Value range UNSIGNED16
Default value 0
Sub-index 0x02
LCP parameter number 51-35
Description External encoder single-turn bits
Access Read/write
Data type UNSIGNED16
PDO mapping Optional
Value range UNSIGNED16
Default value 0
Sub-index 0x03
LCP parameter number 51-36
Description External encoder align bits
Access Read/write
Data type UNSIGNED16
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
340 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
