DD_PrepareDigCamSwitch_ISD51x
Output
ExecuteBOOL
AXIS_REF_-
ISD51x
FileNameSTRING(80)
PathE_OpenPath
BOOLDone
BOOLBusy
DD_ERROR_ISD51xErrorInfo
BOOLError
WORDParseError
DWORDParseErrorDebug
130BE265.10
Illustration 6.55 DD_PrepareDigCamSwitch_ISD51x for
TwinCAT
®
(See Table 6.33 for other available development
environments).
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Output AXIS_REF_ISD51x Reference to the axis/
signal output.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Start transfer of digital
CAM switches data at
rising edge.
FileName STRING[8
0]
“ Filename of the digital
CAM switches le on the
PLC.
pDevice UDINT 0
Automation Studio™ only:
Pointer to the device
name on which the digital
CAM switches le is
located.
Path E_OpenP
ath
PATH_GEN
ERIC
TwinCAT
®
only: The
variable of this type
selects generic or 1 of the
TwinCAT
®
system paths on
the target device.
VAR_OUTPUT
Done BOOL CAM prole and congu-
ration have been
downloaded; Parsing was
successful.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Variable
name
Data
type
Default
value
Description
ParseError WORD Detailed information on
the type of error if there is
a CAM parsing failure.
ParseE-
rrorDebug
DWORD Depending on the cause
given in the output
ParseError, additional
debug information is
given here. Available in
the list of constants:
CamParsingErrors.
Table 6.33 DD_PrepareDigCamSwitch_ISD51x
6.5.4.30 DD_DigitalCamSwitch_ISD51x
This function block activates the digital CAM switches
functionality on the axis. It commands the digital output of
the servo drive to switch in a similar way as a mechanical
CAM controlled switch connected to an axis. Forward and
backward movements are allowed.
This function block only works if the usage of the digital
output is congured accordingly (see
chapter 7.21.5 Parameter 52-05: Digital Output Conguration
(0x2FFF)).
The activation of the digital CAM switches functionality
takes eect immediately.
DD_DigitalCamSwitch_ISD51x
Output
EnableBOOL
AXIS_REF_ISD51x
EnableSwitchesBOOL
BOOLInOperation
BOOLBusy
BOOLError
DD_ERROR_-
ISD51x
ErrorInfo
130BE263.10
Illustration 6.56 DD_DigitalCamSwitch_ISD51x
Programming
VLT
®
Integrated Servo Drive ISD
®
510 System
